Broadcom, HCPL-2630-000E DC Input Transistor Output Dual Optocoupler, Through Hole, 8-Pin DIP
Product Details
Product Details
Optocoupler, 10MBd Logic Gate, Avago Technologies
10 MBd digital optocouplers are suited for isolated communication logic interface and control in industrial power systems, factory automation, power supplies, and medical equipment applications.
10 MBd digital optocouplers are suited for isolated communication logic interface and control in industrial power systems, factory automation, power supplies, and medical equipment applications.
Optocouplers, Avago Technologies
SpecificationsAttribute Value Mounting Type Through Hole Output Device Transistor Maximum Forward Voltage 1.75V Number of Channels 2 Number of Pins 8 Package Type DIP Input Current Type DC Typical Rise Time 24ns Maximum Input Current 20 mA Isolation Voltage 3.75 kVrms Logic Output Yes Typical Fall Time 10ns
| Attribute | Value |
|---|---|
| Mounting Type | Through Hole |
| Output Device | Transistor |
| Maximum Forward Voltage | 1.75V |
| Number of Channels | 2 |
| Number of Pins | 8 |
| Package Type | DIP |
| Input Current Type | DC |
| Typical Rise Time | 24ns |
| Maximum Input Current | 20 mA |
| Isolation Voltage | 3.75 kVrms |
| Logic Output | Yes |
| Typical Fall Time | 10ns |
